File:Surge universal 71641 lightly yellowed teardown circuitdetail 01.jpg
Jump to navigation
Jump to search
Size of this preview: 800 × 450 pixels. Other resolution: 1,600 × 900 pixels.
Original file (1,600 × 900 pixels, file size: 516 KB, MIME type: image/jpeg)
Surge-suppression circuit board installed within a Universal 71641 surge protector. Visible components include the surge-status indicator circuit, film capacitor, metal-oxide varistor (MOV), and associated wiring connections.
